    • Chiron Micro 5

    5-Axis machining center (DEMO MACHINE)


    Product code92-000577
    Manufacturer Chiron
    ModelMicro 5
    Type5-Axis machining center
    ConditionDEMO MACHINE
    ControlSonstige
    Year of manuf.2022
    Availability:immediately


    ...
    René Schmidt

    Technical datasheet
    Share

    Technical Data

    Speed 60,000 rpm
    Power 0.625 kW
    Taper HSK-EZ15
    Toolchanger 60 stations
    Movement X 78 mm
    Movement Y 56 mm
    Movement Z 50 mm
    B-Axis -110° till +110°
    C-Axis 400 rpm
    Rapid traverse X/Y/Z 30/30/30 m/min
    Technology zero point clamping system
    Workpiece change time 10 seconds
    Max. table load 10 kg
    Chip management chip cart
    Coolant management coolant system
    Workpiece measurement Renishaw measuring probe – RMP24-micro
    Tool measurement tool length measurement / break
    Other Automation Feed 5

    Equipment

    • Coolant supply
    • 5-axis simultaneous
    • Elect. handwheel
    • Workpiece measurement
    • Tool measurement
