Mazak QT200MSY Special Edition

  1. Machines
  2. Lathes
  3. Mazak QT200MSY Special Edition
  • Mazak QT200MSY Special Edition - Year of manuf.: 2024 Picture-1

    • Mazak QT200MSY Special Edition

    CNC lathe (New machine)

    The MAZAK QTE-200MY is a highly precise turret lathe designed for robustness and advanced technology. Equipped with live tooling and a Y-axis, it offers versatile machining capabilities and ensures exceptional precision in the production of complex workpieces. Its solid construction makes it ideal for demanding machining tasks.

    A standout feature of the QTE-200MY is its user-friendly control system, regarded as one of the most intuitive on the market. This allows for efficient and straightforward execution of even complex machining processes. Additionally, the machine offers an excellent price-performance ratio, making it the perfect choice for businesses looking for maximum productivity and precision at a competitive price. The MAZAK QTE-200MY combines quality, power, and ease of use, making it a top-tier solution for a wide range of turning and milling applications.

    Product code92-000563
    Manufacturer Mazak
    ModelQT200MSY Special Edition
    TypeCNC lathe
    ConditionNew machine
    ControlMazatrol SmoothG
    Year of manuf.2024
    Special offer price ²199.900,00 €
    Availability:by arrangement


    ...
    René Schmidt

    Technical datasheet
    Share

    Technical Data

    Turning diameter max. 380 mm
    Turning length 500 mm
    Movement X-axis 234 mm
    Movement Y-axis ± 100 mm
    Movement Z-axis 625 mm
    C-axis 0,0001°
    Swing diameter max. 695 mm
    Speed 5,000 rpm
    Power 26 kW
    Torque 465 Nm
    Spindle bearing Ø 76 mm
    Bar capacity 65 mm
    Spindel nose A2-6
    Speed 5,000 U/min
    Power 11 kW
    Torque 90 Nm
    Spindelnose A2-5
    Revolver 12-stations VDI
    Speed live tools 5,000 rpm
    Max. power live tools 5.5 kW
    Max. torque live tools 47 Nm
    Chipmanagement Chip conveyor
    Tool measurement Tool eye
    Tool holder package included
    Sale, installation, and commissioning are limited to Germany only. This procurement proposal is non-binding and subject to change. Modifications and technical errors are reserved. The offer is valid only while supplies last and exclusively for the machine in the described "Special Edition" configuration. All prices are quoted EXW. Services such as transport, installation, and commissioning are available as optional add-ons.

    Equipment

    • Y-Axis
    • Subspindel
    • driven tools
    • Chip conveyor
    • Coolant supply
    • Parts catcher
    • tool holder package
    • Tool measurement
    • high pressure coolant
